| Nominal value output voltage 1 |
24 V
|
|---|---|
| Secondary voltage adjustable |
No
|
| Nominal value output current 1 |
10 A
|
| Power output |
240 W
|
| Voltage type of supply voltage |
AC/DC
|
| Rated supply voltage at AC 50 Hz |
100 V
|
| Rated supply voltage at AC 60 Hz |
100 V
|
| Rated supply voltage at DC |
110 V
|
| Power reserves |
20 %
|
| DC OK relay contact |
Yes
|
| Hot-swap |
No
|
| Input inrush current limiter |
Active
|
| Power factor |
0.97 typical
|
| External input fuse, min |
B-6 A or C-6 A
|
| Power losses |
13.4 W typical
|
| Derating |
6 W/°C
|
| Efficiency |
94.7 % typical
|
| Input inrush current |
6 A/9 A
|
| Output voltage stabilized |
Yes
|
| Rail mounting possible |
Yes
|
| Stabilized |
Yes
|
| Adjustment range |
Fixed
|
| Height |
124 mm
|
|---|---|
| Depth |
117 mm
|
| Direct mounting possible |
No
|
| Width |
39 mm
|
| Degree of protection (IP) |
IP20
|
| Type of electric connection |
Spring clA connection
|
| MTBF |
641 kh (+40 °C, SN29500)
|
| Wall mounting possible |
Yes
|
| Ripple and noise, max |
50 mV
|
|---|---|
| Operating temperature |
-25 °C
|
| Lifetime, min |
109 kh (+40 °C)
|
| Weight |
600 g
|
|---|
| 基本信息 | 出版 |
|---|---|
| Installation Instructions | 1606-IN047 |
| Product Cutsheet | -- |
| 技术数据 | 出版 |
|---|---|
| 1606-td002_-en-p | 1606-TD002 |
- ATEX
- UL Listed
- IECEx Scheme
- Korean KC
- CE
- Australian RCM
- China CCC
- Eurasion Economic Community
截至 2026-01-31，此产品已获得上述多项认证。此日期前后销售的产品，所获认证可能有所不同。请查阅产品标签，确认具体产品所持有的相关认证。
技术规格
| Nominal value output voltage 1 |
24 V
|
|---|---|
| Secondary voltage adjustable |
No
|
| Nominal value output current 1 |
10 A
|
| Power output |
240 W
|
| Voltage type of supply voltage |
AC/DC
|
| Rated supply voltage at AC 50 Hz |
100 V
|
| Rated supply voltage at AC 60 Hz |
100 V
|
| Rated supply voltage at DC |
110 V
|
| Power reserves |
20 %
|
| DC OK relay contact |
Yes
|
| Hot-swap |
No
|
| Input inrush current limiter |
Active
|
| Power factor |
0.97 typical
|
| External input fuse, min |
B-6 A or C-6 A
|
| Power losses |
13.4 W typical
|
| Derating |
6 W/°C
|
| Efficiency |
94.7 % typical
|
| Input inrush current |
6 A/9 A
|
| Output voltage stabilized |
Yes
|
| Rail mounting possible |
Yes
|
| Stabilized |
Yes
|
| Adjustment range |
Fixed
|
| Height |
124 mm
|
|---|---|
| Depth |
117 mm
|
| Direct mounting possible |
No
|
| Width |
39 mm
|
| Degree of protection (IP) |
IP20
|
| Type of electric connection |
Spring clA connection
|
| MTBF |
641 kh (+40 °C, SN29500)
|
| Wall mounting possible |
Yes
|
| Ripple and noise, max |
50 mV
|
|---|---|
| Operating temperature |
-25 °C
|
| Lifetime, min |
109 kh (+40 °C)
|
| Weight |
600 g
|
|---|
图纸
文档
|
Installation Instructions
基本信息
1606-IN047 |
|
Product Cutsheet
基本信息
-- |
|
1606-td002_-en-p
技术数据
1606-TD002 |
| 基本信息 | 出版 |
|---|---|
| Installation Instructions | 1606-IN047 |
| Product Cutsheet | -- |
| 技术数据 | 出版 |
| 1606-td002_-en-p | 1606-TD002 |
认证
- ATEX
- UL Listed
- IECEx Scheme
- Korean KC
- CE
- Australian RCM
- China CCC
- Eurasion Economic Community
截至 2026-01-31，此产品已获得上述多项认证。此日期前后销售的产品，所获认证可能有所不同。请查阅产品标签，确认具体产品所持有的相关认证。
