VersaView 5200 Panel Thin Client
Catalog #: 6200T-15WA
Rockwell Automation announces that as of
March 20, 2023,
the VersaView 5200 Panel Thin Client will be discontinued and no longer available
for sale.
Customers are encouraged to remove references to the affected product(s).
Discontinued Date:
March 20, 2023
Replacement Category:
Engineering Replacement
Rockwell Automation announces that as of
March 20, 2023,
the VersaView 5200 Panel Thin Client will be discontinued and no longer available for
sale.
Customers are encouraged to remove references to the affected product(s).
Discontinued Date:
March 20, 2023
Replacement Category:
Engineering Replacement
| Audio Specifications | DisplayPort Audio |
|---|---|
| Cache Memory | 512 KB |
| Expansion/Connectivity | None |
| Graphics Controller | Intel HD Graphics |
| Hard Disk | 0 GB |
| Height | 298 mm |
| Input Device | PCAP Touch |
| I/O Ports | USB, Ethernet, Serial |
| Networking Specification | 10/100/1000 Mbit |
| Operating Sys Compatibility | ThinManager |
| Power Supply | 24V DC |
| Processor | Intel E3815 |
| RAM Memory | 2 GB |
| Speed | 1.46 GHz |
| Video Specification | DisplayPort |
Sales Info
| Repairable | REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 22.606 |
| Lead Time | 18 |
| Dimension Width | 42.672 |
| Dimension Length | 59.436 |
| Stock Status | NON_STOCKED |
| Weight | 8.027 |
| Weight Unit | KG |
| Dimension Unit | CM |
| Drawings | |
|---|---|
| VersaView5200-5400 (STP) | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| VersaView5200-5400 (STP) Download (ZIP) |
| Product Drawing Drawing (DXF) |
| 类型 | 资源 | 发布 |
|---|---|---|
| General | VersaView5400-5200(PDF) | -- |
| General | Product Cutsheet | -- |
| Selection Guide | view-sg001_-en-p | VIEW-SG001 |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Visit the Technical Documentation Center
Search the Literature Library
- Eurasion Economic Community
- Australian RCM
- UL Listed
This product was certified with the above certifications as of 2025-02-13. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
Looking for more Technotes?
Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.
Search Knowledgebase
Technical Specifications
| Audio Specifications | DisplayPort Audio |
|---|---|
| Cache Memory | 512 KB |
| Expansion/Connectivity | None |
| Graphics Controller | Intel HD Graphics |
| Hard Disk | 0 GB |
| Height | 298 mm |
| Input Device | PCAP Touch |
| I/O Ports | USB, Ethernet, Serial |
| Networking Specification | 10/100/1000 Mbit |
| Operating Sys Compatibility | ThinManager |
| Power Supply | 24V DC |
| Processor | Intel E3815 |
| RAM Memory | 2 GB |
| Speed | 1.46 GHz |
| Video Specification | DisplayPort |
Sales Info
| Repairable | REPAIRABLE |
| Preferred Availability | false |
| Quick Turnaround | false |
| Dimension Height | 22.606 |
| Lead Time | 18 |
| Dimension Width | 42.672 |
| Dimension Length | 59.436 |
| Stock Status | NON_STOCKED |
| Weight | 8.027 |
| Weight Unit | KG |
| Dimension Unit | CM |
Drawings
| Drawings | |
|---|---|
| VersaView5200-5400 (STP) | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| VersaView5200-5400 (STP) Download (ZIP) |
| Product Drawing Drawing (DXF) |
文档
|
VersaView5400-5200(PDF)
General
-- |
|
Product Cutsheet
General
-- |
|
view-sg001_-en-p
Selection Guide
VIEW-SG001 |
| 类型 | 资源 | 发布 |
|---|---|---|
| General | VersaView5400-5200(PDF) | -- |
| General | Product Cutsheet | -- |
| Selection Guide | view-sg001_-en-p | VIEW-SG001 |
Looking for more documentation?
Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.
Visit the Technical Documentation Center
Search the Literature Library
下载
认证
- Eurasion Economic Community
- Australian RCM
- UL Listed
This product was certified with the above certifications as of 2025-02-13. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.
