| Supply voltage DC | 0 V |
|---|---|
| Operating current, max | 40 A |
| Operating voltage | 0V DC |
| Voltage type of supply voltage | DC |
| Degree of protection (IP) | IP20 |
| Width | 12.4 mm |
|---|---|
| Height | 98 mm |
| Weight per module | Approx. 0.13 lb |
| Mounting position | Left |
| Terminal wire gauge | Push-in terminal PT10 AWG20... AWG8 (0.5mm² to 10mm²), Push-in terminal PT2.5 AWG24... AWG14 (0.14mm² to 2.5mm²) |
| Depth | 80 mm |
| Termination type | Push-in |
| Degree of pollution | 2 |
|---|---|
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
| Humidity / damp heat | 96 hr / 95% climate class 3K3 |
| 图纸 | |
|---|---|
| 2-Dimensional Drawing (PDF) | Download (PDF) |
| 3-Dimensional STEP model (STP) | Download (ZIP) |
| Product Drawing | Drawing (DWG) |
| 图纸 |
|---|
| 2-Dimensional Drawing (PDF) Download (PDF) |
| 3-Dimensional STEP model (STP) Download (ZIP) |
| Product Drawing Drawing (DWG) |
登录您的罗克韦尔自动化帐户以查看和下载技术图纸.
登录
| 类型 | 资源 | 出版 |
|---|---|---|
| General | Instructions for Standard 1694 Electronic circuit protection modules | 1694-IN002 |
| General | Topics in Circuit Protection for Power Supplies | 1694-WP001 |
| General | Product Cutsheet | -- |
| General | 1694 Specifications Technical Data | 1492-SG122 |
