| Agency Approvals |
CULus Certified,CE,CULUS
|
|---|---|
| Light Source |
Infrared
|
| Sensing Gap Size |
15mm
|
| Sensing Mode |
Transmitted Beam Pair
|
| Sensitivity Adjustment |
Manually Adjustable
|
| Frame opening lengthwise |
15 mm
|
|---|---|
| Suitable for safety functions |
No
|
| With reflector |
No
|
| Width sensor |
80 mm
|
| Height of sensor |
12 mm
|
| Material housing |
Metal
|
| Setting procedure |
Manual adjustment
|
| Construction type housing |
Special construction
|
| Housing material |
Anodized Aluminium
|
| Response time |
1 ms
|
|---|---|
| Degree of protection (IP) |
IP65
|
| Vibration |
10...55 Hz, 1 mm Alitude, meets or exceeds IEC 600947-5-2
|
| Shock |
30 g with 1 ms pulse duration, meets or exceeds IEC 600947-5-2
|
| Light source |
Non-modulated (continuous) infrared
|
|---|---|
| Number of protected semiconductor outputs |
1
|
| Voltage type |
DC
|
| With time function |
Yes
|
| Wavelength of the sensor |
880 nm
|
| Max. output current |
100 mA
|
| Type of switch function |
Other
|
| Type of switching output |
PNP/NPN
|
| Rated control supply voltage at DC |
10 V
|
| Type of electric connection |
Connector M8
|
| Type of light |
Infrared light
|
| Sensing mode |
Light-/dark switching
|
| Current consumption, max |
40 mA
|
| Power ON delay |
129 ms
|
| Sensitivity adjustment |
25-turn potentiom
|
| Protection type |
Short circuit, reverse polarity, false pulse, overload
|
| Leakage current |
12V supply: 0.78mA @ 10mA load, 6.9mA @ 100mA load, 24V supply: 0.30mA @ 10mA load, 3mA @ 100mA load
|
| LED status |
Green LED: power ON/unblocked light path, Red & green LED blink: short circuit mode, Red LED: output energized
|
| Operating temperature |
-20 °C
|
|---|
| 基本信息 | 出版 |
|---|---|
| Product Cutsheet | -- |
- UKCA DOC
截至 2025-09-10，此产品已获得上述多项认证。此日期前后销售的产品，所获认证可能有所不同。请查阅产品标签，确认具体产品所持有的相关认证。
技术规格
| Agency Approvals |
CULus Certified,CE,CULUS
|
|---|---|
| Light Source |
Infrared
|
| Sensing Gap Size |
15mm
|
| Sensing Mode |
Transmitted Beam Pair
|
| Sensitivity Adjustment |
Manually Adjustable
|
| Frame opening lengthwise |
15 mm
|
|---|---|
| Suitable for safety functions |
No
|
| With reflector |
No
|
| Width sensor |
80 mm
|
| Height of sensor |
12 mm
|
| Material housing |
Metal
|
| Setting procedure |
Manual adjustment
|
| Construction type housing |
Special construction
|
| Housing material |
Anodized Aluminium
|
| Response time |
1 ms
|
|---|---|
| Degree of protection (IP) |
IP65
|
| Vibration |
10...55 Hz, 1 mm Alitude, meets or exceeds IEC 600947-5-2
|
| Shock |
30 g with 1 ms pulse duration, meets or exceeds IEC 600947-5-2
|
| Light source |
Non-modulated (continuous) infrared
|
|---|---|
| Number of protected semiconductor outputs |
1
|
| Voltage type |
DC
|
| With time function |
Yes
|
| Wavelength of the sensor |
880 nm
|
| Max. output current |
100 mA
|
| Type of switch function |
Other
|
| Type of switching output |
PNP/NPN
|
| Rated control supply voltage at DC |
10 V
|
| Type of electric connection |
Connector M8
|
| Type of light |
Infrared light
|
| Sensing mode |
Light-/dark switching
|
| Current consumption, max |
40 mA
|
| Power ON delay |
129 ms
|
| Sensitivity adjustment |
25-turn potentiom
|
| Protection type |
Short circuit, reverse polarity, false pulse, overload
|
| Leakage current |
12V supply: 0.78mA @ 10mA load, 6.9mA @ 100mA load, 24V supply: 0.30mA @ 10mA load, 3mA @ 100mA load
|
| LED status |
Green LED: power ON/unblocked light path, Red & green LED blink: short circuit mode, Red LED: output energized
|
| Operating temperature |
-20 °C
|
|---|
