Micro800 4 Point Analog Output Module

Catalog #: 2085-OF4

Lifecycle status: Active

Lifecycle status: Active

Depth	87mm
Expansion I/O Modules	Micro800 Output Module, Analog, Voltage/Current, 4 Channels, Bipolar, +-10V, 0-20mA
Height	90mm
I/O Isolation	Isolated
I/O Status Indication	LED
Output	4 Point, +-10V, 0-20mA
Temperature Rating	-20…65 °C (-4…149 °F)

Sales Info

Repairable	NOT_REPAIRABLE
Preferred Availability	true
Quick Turnaround	false
Dimension Height	8.7
Lead Time	5
Dimension Width	9.0
Dimension Length	2.8
Stock Status	STOCKED
Weight	0.19
Weight Unit	KG
Dimension Unit	CM

Drawings
Dimension Drawing (PDF)	Download (PDF)
3D STP (STEP) Model	Download (ZIP)
Product Drawing	Drawing (DXF)

Drawings
Dimension Drawing (PDF) Download (PDF)
3D STP (STEP) Model Download (ZIP)
Product Drawing Drawing (DXF)

类型	资源	发布
General	Product Cutsheet	--

Looking for more documentation?

Find curated technical documentation for this product in the Technical Documentation Center, or search our full Literature Library.

Visit the Technical Documentation Center Search the Literature Library

Australian RCM
Korean Register of Shippin
UL Listed
Bureau Veritas

This product was certified with the above certifications as of 2025-05-14. Products sold before or after this date might carry different certifications. Please review the product label to check for the certifications your specific product carries.

Looking for more Technotes?

Find questions and answers from Rockwell Automation technical experts for this product in our Knowledgebase.

Search Knowledgebase

Technical Specifications

Depth	87mm
Expansion I/O Modules	Micro800 Output Module, Analog, Voltage/Current, 4 Channels, Bipolar, +-10V, 0-20mA
Height	90mm
I/O Isolation	Isolated
I/O Status Indication	LED
Output	4 Point, +-10V, 0-20mA
Temperature Rating	-20…65 °C (-4…149 °F)
