| Temperature Rating | -20…65 °C (-4…149 °F) |
|---|
| Suitable for safety functions | False |
|---|---|
| With optical interface | False |
| Supporting protocol for TCP/IP | False |
| Supporting protocol for DeviceNet | True |
| Supporting protocol for other bus systems | False |
| Redundancy | False |
| IO link master | False |
| Supporting protocol for DeviceNet Safety | True |
| Supporting protocol for EtherNet/IP | False |
| Transmission rate | 19.2 kbps |
| Data transmission type | Serial |
| Supporting protocol | Modbus RTU (RS232 and RS485) |
| Wire size | 0.14...1.5 mm² (26...16 AWG) solid copper wire or, 0.14...1.0 mm² (22...18 AWG) stranded copper wire, Rated at 90 °C (194 °F) insulation max |
| Supporting protocol for LON | False |
| Supporting protocol for ASI | False |
| Supporting protocol for PROFIBUS | False |
| Supporting protocol for CAN | False |
| Supporting protocol for INTERBUS | False |
| Supporting protocol for KNX | False |
| Supporting protocol for Modbus | False |
| Supporting protocol for Data-Highway | False |
| Supporting protocol for SUCONET | False |
| With potential separation | False |
| Supporting protocol for SERCOS | False |
| Supporting protocol for INTERBUS-Safety | False |
| Supporting protocol for AS-Interface Safety at Work | False |
| Supporting protocol for Foundation Fieldbus | False |
| Supporting protocol for PROFINET CBA | False |
| Supporting protocol for PROFINET IO | False |
| Supporting protocol for PROFIsafe | False |
| Supporting protocol for SafetyBUS p | False |
| SIL according to IEC 61508 | None |
| Cable length using RS485, Max | 1000 |
| Isolated voltage | 500V AC |
| Terminal screw torque | 0.22...0.25 Nm (1.95...2.21 in-lb) (using a 2.5 mm (0.10 in.) flat-blade screwdriver) |
| Surrounding air temperature, max | 65 °C |
|---|---|
| Emissions | CISPR 11 (IEC 61000-6-4): Class A |
| Vibration | IEC 60068-2-6 (Test Fc, operating), 2 G @ 10...500 Hz |
| ESD immunity | IEC 61000-4-2: 6 kV contact discharges, 8 kV air discharges |
| EFT/B immunity | IEC 61000-4-4: ± 2kV @ 5kHz on communication ports |
| Shock | Operating: 25 G, IEC 60068-2-27 (Test Ea, unpackaged shock) |
| Conducted RF immunity | IEC 61000-4-6, 10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz |
| Surge transient immunity | IEC 61000-4-5: ± 2 kV line-earth(CM) on communication ports |
| Nonoperating temperature | -40...85 °C (-40...185 °F), IEC60068-2-1 (Test Ad, operating cold), IEC60068-2-2 (Test Bd, operating dry heat), IEC 60068-2-14 (Test Nb, operating thermal shock) |
| Operating temperature | -20...65 °C (-4...149 °F), IEC 60068-2-1 (Test Ad, operating cold), IEC 60068-2-2 (Test Bd, operating dry heat), IEC 60068-2-14 (Test Nb, operating thermal shock) |
| Radiated RF immunity | IEC 61000-4-3: 10V/m with 1 kHz sine-wave 80% AM from 80...2000 MHz, 10V/m with 200 Hz 50% pulse 100% AM @ 900 MHz, 10V/m with 200 Hz 50% pulse 100% AM @ 1890 MHz, 10V/m with 1 kHz sine-wave 80% AM from 2000...2700 MHz, |
| North American temperature code | T4 |
|---|
| Mounting torque | 0.2 nm |
|---|
Sales Info
| Repairable | NOT_REPAIRABLE |
| Preferred Availability | true |
| Quick Turnaround | false |
| Dimension Height | 2.0 |
| Lead Time | 5 |
| Dimension Width | 3.15 |
| Dimension Length | 6.2 |
| Stock Status | NON_STOCKED |
| Weight | 0.635 |
| Weight Unit | KG |
| Dimension Unit | CM |
| Drawings | |
|---|---|
| 3D STP (STEP) Model | Download (ZIP) |
| Product Drawing | Drawing (DXF) |
| Drawings |
|---|
| 3D STP (STEP) Model Download (ZIP) |
| Product Drawing Drawing (DXF) |
Sign in to your Rockwell Automation account to view and download technical drawings.
登录
| 类型 | 资源 | 发布 |
|---|---|---|
| General | Installation Guide | -- |
| General | Brochure | -- |
| General | Product Cutsheet | -- |
| General | Wiring Diagram | -- |
| User Manual | 2080-um004_-en-e | 2080-UM004 |
| User Manual | Micro800 Plug-in Modules User Manual | 2080-UM002 |
